Programmable HV DC Power Supply : POWERTRON Programmable HV DC Power Supply delivers stable, accurate, and fully controllable high-voltage output for advanced industrial, R&D, and testing applications. Designed with digital control technology, it offers wide programmable voltage/current ranges, low ripple, fast response time, and high efficiency—making it ideal for insulation testing, capacitor charging, X-ray equipment, power electronics, and material research. With multiple communication interfaces, user-friendly programming options, and comprehensive protection features, POWERTRON HV supplies ensure safe, reliable, and repeatable performance even in demanding environments. Built to meet stringent quality and safety standards, POWERTRON provides dependable high-voltage power for mission-critical operations. Choose POWERTRON for precision high-voltage output, robust safety, and intelligent programmable control for modern HV testing and development needs.

Programmable HV DC Power Supply

Features:

  • Max.Rated Output 500W To 8Kw, Customized Up To 50KW
  • Max.Rated Voltage From +1000V To +50Kv
  • Option For Negative Output From -1000V To -50Kv
  • Low Ripple, High Stability
  • No Overshoot During Startup
  • Soft Start By Hardware & Adjustable Voltage Rise Time By Software
  • List Mode Function, Auto Run Function
  • Preset Function, Setting Of Voltage And Current With Output Open Circuit
  • Multiple Protections: Ovp, Otp, Acf And Current Limit Protections
  • Standard Interface: Rs232 & Rs485, Support Modbus-Rtu Commands
  • Optional Interface: Dc 0~5V, 0~10V Or 4-20Ma Interface For Control And Feedback; Lan Interface.
Power Utilities
Power Utilities
Aerospace & Defence Electronics
Aerospace & Defence Electronics
Semiconductor Manufacturing
Semiconductor Manufacturing
R & D Laboratories
R & D Laboratories
Renewable Energy
Renewable Energy
Automotive & EV Industry
Automotive & EV Industry
Industrial Automation
Industrial Automation

Available Variants

Model (600W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-1KP600-HPDP 0~1000V 0~600mA 0~1050V ≤0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-1KN600-HPDP 200~1000V 0~600mA 200~1050V ≤0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-1.2KP500-HPDP 0~1200V 0~500mA 0~1260V ≤0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-1.2KN500-HPDP 240~1200V 0~500mA -240~1260V ≤0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-1.5KP400-HPDP 0~1500V 0~400mA 0~1575V s0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-1.5KN400-HPDP 300~1500V 0~400mA 300~1575V ≤0.05%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-2KP300-HPDP 0~2000V 0~300mA 0~2100V s0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-2KN300-HPDP 400~2000V 0~300mA 400~2100V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-3KP200-HPDP 200~3000V 0~200mA 200~3150V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-3KN200-HPDP 600~3000V 0~200mA 600~3150V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-4KP150-HPDP 200~40 00V 0~150mA 200~4200V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-4KN150-HPDP 800~4000V 0~150mA 800~4200V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-5KP120-HPDP 300~5000V 0~120mA 300~5250V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
PIPL-5KN120-HPDP 1000~5000V 0~120mA 1000~5250V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-6KP100-HPDP 400~60 00V 0~100mA 400~6120V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-6KN100-HPDP 1200~6000V 0~100mA -1200~ 6120V ≤0.1%FS 1V 0.1mA 1V 1V 0.1mA
PIPL-8KP75-HPDP 500~80 00V 0~75mA 500~8400V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
PIPL-8KN75-HPDP 1600~8000V 0~75mA 1600~8400V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
PIPL-10KP60-HPDP 800~10000V 0~60mA 800~1050 0V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
PIPL-10KN60-HPDP 2000~10000V 0~60mA 2000~10500V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
PIPL-12KP50-HPDP 1000~12000V 0~50mA 1000~12600V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
PIPL-12KN50-HPDP 2400~12000V 0~50mA 2400~12600V ≤0.1%FS 1V 0.01mA 1V 1V 0.01mA
Model (1200W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-1KP1200-HPDP 0~1000V 0 ~ 1200mA 0 ~ 1050V 0 ~ 1200mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1KN1200-HPDP -200 ~ -1000V 0 ~ 1200mA -200 ~ -1050V 0 ~ 1200mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1.2KP1000-HPDP 0 ~ 1200V 0 ~ 1000mA 0 ~ 1260V 0 ~ 1000mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1.2KN1000-HPDP -240 ~ -1200V 0 ~ 1200mA -240 ~ -1260V 0 ~ 1200mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1.4KP800-HPDP 0 ~ 1500V 0 ~ 800mA 0 ~ 1575V 0 ~ 800mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-1.5KN800-HPDP -300 ~ -1500V 0 ~ 800mA -300 ~ -1575V 0 ~ 800mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-2KP600-HPDP 0 ~ 2000V 0 ~ 600mA 0 ~ 2100V 0 ~ 600mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-2KN600-HPDP -400 ~ -2000V 0 ~ 600mA -400 ~ -2100V 0 ~ 600mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-3KP400-HPDP 200 ~ 3000V 0 ~ 400mA 200 ~ 3150V 0 ~ 400mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-3KN400-HPDP -600 ~ -3000V 0 ~ 400mA -600 ~ -3150V 0 ~ 400mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-4KP300-HPDP 200 ~ 4000V 0 ~ 300mA 200 ~ 4200V 0 ~ 300mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-4KN300-HPDP -800 ~ -4000V 0 ~ 300mA -800 ~ -4200V 0 ~ 300mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-5KP240-HPDP 300 ~ 5000V 0 ~ 240mA 300 ~ 5250V 0 ~ 240mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-5KN240-HPDP -1000 ~ -5000V 0 ~ 240mA -1000 ~ -5250V 0 ~ 240mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-6KP200-HPDP 400 ~ 6000V 0 ~ 200mA 400 ~ 6120V 0 ~ 200mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-6KN200-HPDP -1200 ~ -6000V 0 ~ 200mA -1200 ~ -6120V 0 ~ 200mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-8KP150-HPDP 500 ~ 8000V 0 ~ 150mA 500 ~ 8400V 0 ~ 150mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-8KN150-HPDP -1600 ~ -8000V 0 ~ 150mA -1600 ~ -8400V 0 ~ 150mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-10KP120-HPDP 800 ~ 10000V 0 ~ 120mA 800 ~ 10500V 0 ~ 120mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-10KN120-HPDP -2000 ~ -10000V 0 ~ 120mA -2000 ~ -10500V 0 ~ 120mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-12KP100-HPDP 1000 ~ 12000V 0 ~ 100mA 1000 ~ 12500V 0 ~ 100mA ≤0.1% FS 1V 0.01mA 1V 0.01mA
PIPL-12KN100-HPDP -2400 ~ -12000V 0 ~ 100mA -2400 ~ -12500V 0 ~ 100mA ≤0.1% FS 1V 0.01mA 1V 0.01mA
Model (2400W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-1KP2400-HPDP 0~1000V 0~2400mA 0~1050V 0~2400mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1KN2400-HPDP -200~-1000V 0~2400mA -200~-1050V 0~2400mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-2KP2000-HPDP 0~2000V 0~2000mA 0~2100V 0~2000mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-2KN2000-HPDP -240~-1200V 0~2000mA -240~-1260V 0~2000mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1.5KP1600-HPDP 0~1500V 0~1600mA 0~1575V 0~1600mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-1.5KN1600-HPDP -300~-1500V 0~1600mA -300~-1575V 0~1600mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-2.8KP1200-HPDP 0~2800V 0~1200mA 0~2100V 0~1200mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-2.8KN1200-HPDP -400~-2000V 0~1200mA -400~-2100V 0~1200mA ≤0.1% FS 1V 1mA 1V 1mA
PIPL-3KP800-HPDP 200~3000V 0~800mA 200~3150V 0~800mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-3KN800-HPDP -600~-3000V 0~800mA -600~-3150V 0~800mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-4KP600-HPDP 200~4000V 0~600mA 200~4200V 0~600mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-4KN600-HPDP -800~-4000V 0~600mA -800~-4200V 0~600mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-5KP480-HPDP 300~5000V 0~480mA 300~5250V 0~480mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-5KN480-HPDP -1000~-5000V 0~480mA -1000~-5250V 0~480mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-6KP400-HPDP 400~6000V 0~400mA 400~6120V 0~400mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-6KN400-HPDP -1200~-6000V 0~400mA -1200~-6120V 0~400mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-8KP300-HPDP 500~8000V 0~300mA 500~8400V 0~300mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-8KN300-HPDP -1600~-8000V 0~300mA -1600~-8400V 0~300mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-10KP240-HPDP 800~10000V 0~240mA 800~10500V 0~240mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
PIPL-10KN240-HPDP -2000~-10000V 0~240mA -2000~-10500V 0~240mA ≤0.1% FS 1V 0.1mA 1V 0.1mA
Model (4000W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-8005000-HPDP 0~800V 0~5000mA 0~840V ≤0.1% FS 0.1V 1mA 0.1V 0.1V 1mA
PIPL-1KP4000-HPDP 0~1000V 0~4000mA 0~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KP4000-HPDP ~200~1000V 0~4000mA ~200~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KP3300-HPDP 0~1200V 0~3300mA 0~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KN3300-HPDP ~240~1200V 0~3300mA ~240~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.5KP2600-HPDP 0~1500V 0~2600mA 0~1575V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.5KN2600-HPDP ~300~1500V 0~2600mA ~300~1575V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KP2000-HPDP 0~2000V 0~2000mA 0~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KN2000-HPDP ~400~2000V 0~2000mA ~400~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KP1300-HPDP 400~3000V 0~1300mA 400~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KN1300-HPDP 600~3000V 0~1300mA 600~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KP1000-HPDP 550~4000V 0~1000mA 550~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KN1000-HPDP 800~4000V 0~800mA 800~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-5KP800-HPDP 1000~5000V 0~800mA 1000~5250V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
PIPL-6KP660-HPDP 800~6000V 0~660mA 800~6120V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
PIPL-6KN660-HPDP ~1200~6000V 0~660mA ~1200~6120V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
Model (5000W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-1KP5000-HPDP 0~1000V 0~5000mA 0~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1KN5000-HPDP ~200~1000V 0~5000mA ~200~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KP4160-HPDP 0~1200V 0~4160mA 0~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KN4160-HPDP ~240~1200V 0~4160mA ~240~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.5KP3300-HPDP 0~1500V 0~3300mA 0~1575V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.5KN3300-HPDP ~300~1500V 0~3300mA ~300~1575V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KP2500-HPDP 0~2000V 0~2500mA 0~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KN2500-HPDP ~400~2000V 0~2500mA ~400~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KP1600-HPDP 400~3000V 0~1600mA 400~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KN1600-HPDP 600~3000V 0~1600mA 600~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KP1250-HPDP 550~4000V 0~1250mA 550~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KN1250-HPDP 800~4000V 0~1250mA 800~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-5KP1000-HPDP 700~5000V 0~1000mA 700~5250V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-5KN1000-HPDP 1000~5000V 0~1000mA 1000~5250V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-6KP830-HPDP 800~6000V 0~830mA 800~6120V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
PIPL-6KN830-HPDP ~1200~6000V 0~830mA ~1200~6120V ≤0.1% FS 1V 0.1mA 1V 1V 0.1mA
Model (3000W) Rated Output Voltage Voltage Ripple Programming Resolution Display Resolution
V A OVP V A OVP V A
PIPL-1KP3000-HPDP 0~1000V 0~3000mA 0~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1KN3000-HPDP 200~1000V 0~3000mA ~200~1050V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KP2500-HPDP 0~1200V 0~2500mA 0~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.2KN2500-HPDP ~240~1200V 0~2500mA ~240~1260V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-1.5KP2000-HPDP 0~1500V 0~2000mA 0~1575V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KP1500-HPDP 0~2000V 0~1500mA 0~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-2KN1500-HPDP ~400~2000V 0~1500mA ~400~2100V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KP1000-HPDP 200~3000V 0~1000mA 200~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-3KN1000-HPDP 300~3000V 0~1000mA 300~3150V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KP750-HPDP 200~4000V 0~750mA 200~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-4KN750-HPDP 800~4000V 0~750mA 800~4200V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-5KP600-HPDP 300~5000V 0~600mA 300~5250V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-5KN600-HPDP 1000~5000V 0~600mA 1000~5250V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-6KP500-HPDP 400~6000V 0~500mA 400~6120V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-6KN500-HPDP ~1200~6000V 0~500mA ~1200~6120V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-8KP375-HPDP 500~8000V 0~375mA 500~8400V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-8KN375-HPDP 1600~8000V 0~375mA 1600~8400V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-10KP300-HPDP 800~10000V 0~300mA 800~10500V ≤0.1% FS 1V 1mA 1V 1V 1mA
PIPL-10KN300-HPDP ~2000~10000V 0~300mA ~2000~10500V ≤0.1% FS 1V 1mA 1V 1V 1mA
